Part No.
|
Size
|
A
|
B
|
C
|
|
inches
|
inches
|
mm
|
inches
|
mm
|
inches
|
mm
|
|
TP-UNF-05
|
5/16-24
|
0.440
|
11.18
|
0.180
|
4.57
|
0.440
|
11.18
|
|
TP-UNF-10
|
3/8-24
|
0.500
|
12.70
|
0.180
|
4.57
|
0.460
|
11.68
|
|
TP-UNF-15
|
7/16-20
|
0.620
|
15.75
|
0.190
|
4.83
|
0.530
|
13.46
|
|
TP-UNF-20
|
1/2-20
|
0.680
|
17.27
|
0.250
|
6.35
|
0.530
|
13.46
|
|
TP-UNF-25
|
9/16-18
|
0.810
|
20.57
|
0.250
|
6.35
|
0.500
|
12.70
|
|
TP-UNF-30
|
5/8-18
|
0.810
|
20.57
|
0.250
|
6.35
|
0.593
|
13.05
|
|
TP-UNF-35
|
3/4-16
|
0.940
|
23.88
|
0.250
|
6.35
|
0.750
|
12.70
|
|
TP-UNF-40
|
7/8-14
|
1.060
|
26.92
|
0.250
|
6.35
|
0.870
|
22.10
|
|
TP-UNF-45
|
1-1/16-12
|
1.250
|
31.75
|
0.250
|
6.35
|
0.890
|
22.61
|
|
TP-UNF-50
|
1-1/16-14
|
1.310
|
33.27
|
0.250
|
6.35
|
1.120
|
28.45
|
|
TP-UNF-55
|
1-5/16-12
|
1.500
|
38.10
|
0.250
|
6.35
|
0.930
|
23.62
|
|
